USGI Push Switch 99-452-6KM-24206, 5930-01-351-6141

$419.00
Availability: In-Stock
Quantity
Call: 702-268-8156
USGI Push Switch 99-452-6KM-24206, 5930-01-351-6141

TECHNICAL CHARACTERISTICS

ACTUATOR COLOR
(AFVA) GREEN SINGLE ACTUATOR
ACTUATOR HEIGHT
(AFUS) 0.265 INCHES MAXIMUM
ACTUATOR INSCRIPTION
(AFVE) WHITE/BLACK SINGLE ACTUATOR
ACTUATOR LENGTH
(AFGK) 0.960 INCHES NOMINAL
ACTUATOR WIDTH
(AFUT) 0.960 INCHES NOMINAL
ACTUATOR STYLE
(AFUQ) RECTANGULAR
BODY HEIGHT
(ADAU) 0.960 INCHES NOMINAL
BODY STYLE
(AAQL) PANEL MOUNTED
BODY WIDTH
(ADAT) 0.960 INCHES NOMINAL
CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE
(CXQR) 7.000 AMPERES RESISTIVE DC AND 7.000 AMPERES RESISTIVE AC
FEATURES PROVIDED
(CBBL) ACTUATOR SEAL AND LAMP HOLDER
HAZARDOUS LOCATIONS/ENVIRONMENTAL PROTECTION
(ABFE) MOISTURE RESISTANT AND CORROSION RESISTANT
ILLUMINATED ACTUATOR COLOR
(AFVB) GREEN SINGLE ACTUATOR
INCLOSURE TYPE
(AKNA) FULLY INCLOSED
NONPILE-UP CONTACT ARRANGEMENT
(CRLD) 2 POLE, DOUBLE THROW, BOTH POSITIONS MAINTAINED SINGLE SWITCH UNIT
OVERALL HEIGHT
(ABKW) 0.960 INCHES NOMINAL
OVERALL LENGTH
(ABHP) 1.505 INCHES NOMINAL
OVERALL WIDTH
(ABMK) 0.960 INCHES NOMINAL
MAXIMUM VOLTAGE RATING IN VOLTS
(AFXE) 28.0 DC AND 115.0 AC
MOUNTING METHOD
(AXGY) PANEL
MOUNTING SURFACE TO TERMINAL END DISTANCE
(AJWX) 1.060 INCHES NOMINAL
PRECIOUS MATERIAL AND LOCATION
(PMLC) TERMINAL SURFACES GOLD
TERMINAL TYPE AND QUANTITY
(TTQY) 11 TAB, SOLDER LUG
CASE MATERIAL
(ADTV) METAL
PRECIOUS MATERIAL
(PRMT) GOLD




THE SUBJECT MATERIAL LISTED FOR SALE IS NEW GOVERNMENT SURPLUS. THIS ITEM MAY NOT CURRENTLY BE CERTIFIED FOR USE ON FAA REGISTERED AIRCRAFT. BUYER ASSUMES FULL RESPONSIBILITY FOR OBTAINING THE NECESSARY OEM AND/OR REGULATORY AGENCY APPROVAL PRIOR TO THE USE OF, OR RESALE OF, THE LISTED ITEM(S).
