USGI Air Hose 4720-00-108-5620, HC200B96, 8148650, MIL-H-81581, MS22055B96
-
Regular price
-
-
Sale price
-
$229.95
USGI Air Hose 4720-00-108-5620, HC200B96, 8148650, MIL-H-81581, MS22055B96
- COUPLING STYLE
- (CXMG) OXYGEN HOSE CLAMP SECOND END
- III MATERIAL
- (MATT) COPPER ALLOY 1ST END COUPLING
- CONNECTION TYPE
- (AWLS) COUPLING FIRST END
- III MATERIAL
- (MATT) STEEL 2ND END COUPLING
- SURFACE TREATMENT
- (SFTT) CADMIUM 1ST END COUPLING OR ZINC 1ST END COUPLING
- END INSIDE DIAMETER
- (CPYG) 0.844 INCHES MINIMUM AND 0.875 INCHES MAXIMUM FIRST END
- CONNECTION STYLE
- (AHNC) ROUND SECOND END
- CONNECTION TYPE
- (AWLS) COUPLING SECOND END
- CONNECTION TYPE
- (AWLS) SOFT FIRST END
- COUPLING STYLE
- (CXMG) CONNECTOR, OXYGEN HOSE TO REGULATOR (NOTE: APPLICABLE TO HOSE ASSEMBLY, AIR BREATHING ONLY.) SECOND END
- COUPLING STYLE
- (CXMG) OXYGEN HOSE CLAMP FIRST END
- CROSS-SECTIONAL SHAPE STYLE
- (AAGR) ROUND
- END OVERALL LENGTH
- (AGQM) 0.938 INCHES MINIMUM AND 1.000 INCHES MAXIMUM BOTH ENDS
- FEATURES PROVIDED
- (CBBL) OZONE RESISTANT AND RESTRAINT CORD
- FSC APPLICATION DATA
- (ZZZV) OXYGEN SYSTEM A-37B AIRCRAFT
- HOSE WEIGHT
- (AMPY) 5.000 OUNCES PER LINEAR FOOT
- INSIDE DIAMETER
- (AARX) 0.750 INCHES NOMINAL FIRST END
- OUTSIDE DIAMETER
- (ABKV) 1.094 INCHES MINIMUM AND 1.250 INCHES MAXIMUM BOTH ENDS
- MATERIAL DOCUMENT AND CLASSIFICATION
- (MDCL) QQ-B-626,COMP 22,1/2H FED SPEC SINGLE MATERIAL RESPONSE 1ST END COUPLING
- MATERIAL
- (MATT) COPPER ALLOY 1ST END COUPLING
- MATERIAL
- (MATT) COTTON AND FIBERGLASS 1ST PLY
- MATERIAL
- (MATT) STEEL 2ND END COUPLING
- MEASURING METHOD AND LENGTH
- (CRXX) 96.000 INCHES NOMINAL OVERALL
- SPECIAL FEATURES
- (FEAT) END SIMILARITY:NOT IDENTICAL; HOSE STYLE:HELICALLY WOUND CONTINUOUS WIRE SUPPORTED, STYLE NO. 4 FROM OLD FIIG A22900; HOSE MATERIAL:CORROSION RESISTANT STEEL WIRE (QQ-W-423 FORM 1 COMP 302 COND. B), FIBER POLYAMIDE AND FABRIC; COMMUNICATION CABLE:NOT INCLUDED
- STYLE DESIGNATOR
- (STYL) HELICALLY WOUND CONTINOUS WIRE SUPPORTED
- SURFACE TREATMENT DOCUMENT AND CLASSIFICATION
- (STDC) QQ-P-416,TYPE 1,CLASS 1 FED SPEC 1ST TREATMENT RESPONSE OR QQ-Z-325,TYPE 1,CLASS 2 FED SPEC 2ND TREATMENT RESPONSE 1ST END COUPLING
- SURFACE TREATMENT
- (SFTT) CADMIUM OR ZINC 1ST END COUPLING
- SURFACE TREATMENT
- (SFTT) CHROMATE ZINC 2ND END COUPLING
