Solenoid Valve G1/4'' NC Stainless Steel FFKM -12bar/0-174psi 24VDC 0330 181228
- Regular price
-
$109.95 - Regular price
-
- Sale price
-
$109.95
Shipping calculated at checkout.
Burkert Solenoid Valve G1/4'' NC Stainless Steel FFKM -12bar/0-174psi 24VDC 0330 181228
Burkert 2/2 way solenoid valve (type 0330) with G 1/4 inch threads and a 24 V DC coil. The circuit function of the solenoid valve is normally closed (voltage = open). The valve is direct operating, so no differential pressure required. Suitable for max media temperatures of 90 °C (194 °F) and a pressure range of to 12 bar (0 to 174 psi). Housing of stainless steel with FFKM sealing and a 2 mm orifice. The Kv-value is 0.08 m3/h (1.33 l/min at dp = 1 bar water).
Couldn't load pickup availability
-
Hurry, only 1 item left in stock!
