New Genuine Bendix E-7 Series Dual Circuit Heavy Duty Foot Brake Valve 288268N
This valve features a side or Rear port configuration, making it a versatile addition to any vehicle.
Mounting (Valve Body)
5/16-18 UNC-3B (3x)
Mounting (Vehicle)
3/8-16 UNC-3B (3x)
Mounting Plate Included
Yes
Rubber Boot Included
No
Port Configuration
Side / Rear
Supply (11) Port 1
1/4-18 NPT
Supply (11) Port 2
1/4-18 NPT
Supply (11) Port 3
1/2-14 NPT
Supply (12) Port 1
1/4-18 NPT
Supply (12) Port 2
1/4-18 NPT
Supply (12) Port 3
1/2-14 NPT
Supply (12) Port 4
1/8-27 NPT
Delivery (21) Port 1
1/4-18 NPT
Delivery (21) Port 2
1/4-18 NPT
Delivery (21) Port 3
1/2-14 NPT
Delivery (22) Port 1
1/4-18 NPT
Delivery (22) Port 2
1/4-18 NPT
Delivery (22) Port 3
1/2-14 NPT
Exhaust Port
Dust Shield
Differential Pressure
3.0 PSI
Graduation Spring Style
Rubber
Regulatory Compliance
FMVSS 121
Manifold Included
No
Pedal Included
Yes
Pedal Style
Suspended (Pedal)
Pedal Pad Included
Yes
Pedal Material
Cast Aluminum
Pedal Length (from Pivot)
9.69 IN
Pedal Length (Overall)
11.52 IN
Pedal Offset
No Offset
Initial Pedal Angle
48°
Total Pedal Travel
17°
Plunger Material
Steel
