AP-12-638-3 AIRPAX TOGGLE SWITCH 47/420HZ 8.5A 120/240V 2P 5WIRE SM-C-667918

AP-12-638-3 AIRPAX TOGGLE SWITCH 47/420HZ 8.5A 120/240V 2P 5WIRE SM-C-667918

$119.95

Availability: In-Stock

Add To Wishlist

Add To Compare

Call: 702-268-8156

Description
Payment Info

AP-12-638-3 AIRPAX TOGGLE SWITCH 47/420HZ 8.5A 120/240V 2P 5WIRE SM-C-667918

UNPACKAGED UNIT WEIGHT(PKWT) 3.600 OUNCESUNABLE TO DECODE(AEFN) UNABLE TO DECODE AND UNABLE TO DECODEUNABLE TO DECODE(ADTV) UNABLE TO DECODEFREQUENCY IN HERTZ(FREQ) 47.0 ALL LOCATIONS OR 420.0 ALL LOCATIONSCASE MATERIAL(ADTV) METALMAXIMUM CONTINUOUS LOAD CURRENT RATING PER POLE(CPLM) 8.5 AMPERES AC FIRST LOCATION AND 17.0 AMPERES AC FIRST LOCATION17.0 AMPERES AC SECOND LOCATIONUNPACKAGED UNIT WEIGHT(CTJS) 3.600 OUNCES NOMINALULTIMATE TRIP RATING OF CONTINUOUS CURRENT RATING PER POLE IN PERCENT(CPRN) 115.0 ALL LOCATIONSTRIP RELEASE METHOD(CPRJ) MAGNETIC ALL LOCATIONSTRIP RELEASE CHARACTERISTIC(CPRL) TIME DELAY ALL LOCATIONSTRIP DELAY TIME IN SECONDS PER RATED CONTINUOUS CURRENT(CQWN) 0.090 MINIMUM AT 200 PCT AND 1.000 MAXIMUM AT 200 PCT FIRST LOCATIONTRIP DELAY TIME IN SECONDS PER RATED CONTINUOUS CURRENT(CQWN) 0.090 MINIMUM AT 200 PCT AND 0.600 MAXIMUM AT 200 PCT SECOND LOCATIONTHREAD SERIES DESIGNATOR(THSD) UNEFTHREAD PITCH DIAMETERS(AAJE) +0.3503 TO 0.3537 INCHESTHREAD QUANTITY PER INCH(CMLP) 32TERMINAL TYPE AND QUANTITY(TTQY) 5 WIRE HOOKSTORAGE TYPE(BBRG) GENERAL PURPOSE WAREHOUSESPECIAL HANDLING FEATURE(BBRJ) MAGNETICRESET METHOD(CPRQ) MANUALPOLE QUANTITY(AKPX) 2NONTURN DEVICE RADIUS(AEFP) 0.610 INCHES MINIMUM AND 0.640 INCHES MAXIMUMNONTURN DEVICE LENGTH(AEFQ) 0.130 INCHES NOMINALNONTURN DEVICE DIAMETER(AEFS) 0.235 INCHES MINIMUM AND 0.265 INCHES MAXIMUMNOMINAL THREAD SIZE(CQJX) 0.375 INCHESMOUNTING SURFACE TO TERMINAL END DISTANCE(AJWX) 1.780 INCHES MAXIMUMMOUNTING FACILITY TYPE AND QUANTITY(AXHR) 1 THREADED BUSHING W/PANEL SEALMAXIMUM INTERRUPTING CAPACITY CURRENT TYPE AND RATING PER POLE IN AMPS(CPRG) 500.0 AC AND 300.0 AC ALL LOCATIONSMAXIMUM CONTINUOUS LOAD CURRENT RATING PER POLE(CPLM) 8.5 AMPERES AC AND 17.0 AMPERES AC FIRST LOCATIONMAXIMUM CONTINUOUS LOAD CURRENT RATING PER POLE(CPLM) 17.0 AMPERES AC SECOND LOCATIONOPERATING VOLTAGE TYPE AND RATING PER POLE IN VOLTS(CPRF) 120.0 AC AND 240.0 AC ALL LOCATIONSMANUAL ACTUATOR TYPE AND QUANTITY(CPRT) 1 TOGGLEMAIN CONTACT TRIPPING MECHANISM TYPE(CPRR) TRIP FREEINTERNAL TRIP RELEASE CONFIGURATION(CPSM) SHUNT TRIP FIRST LOCATIONINTERNAL TRIP RELEASE CONFIGURATION(CPSM) SERIES TRIP SECOND LOCATIONINCLOSURE PROTECTION TYPE FOR WHICH DESIGNED(CQXF) HERMETICALLY SEALED AND SHOCK RESISTANT AND VIBRATION RESISTANTFREQUENCY IN HERTZ(FREQ) 47.0 OR 420.0 ALL LOCATIONSFRAGILITY FACTOR(AFJN) MODERATELY RUGGEDCIRCUIT PROTECTION TYPE(CPRH) OVERCURRENT ALL LOCATIONSCENTER TO CENTER DISTANCE BETWEEN TERMINALS PARALLEL TO WIDTH(AEBQ) 0.610 INCHES MINIMUM AND 0.640 INCHES MAXIMUMCENTER TO CENTER DISTANCE BETWEEN TERMINALS PARALLEL TO LENGTH(AEBP) 0.860 INCHES MINIMUM AND 0.890 INCHES MAXIMUMBUSHING LENGTH(ABXD) 0.380 INCHES MAXIMUMBODY WIDTH(ADAT) 1.281 INCHES MAXIMUMBODY STYLE(AAQL) MULTIPOLE-SINGLE ACTUATOR TYPEBODY LENGTH(ADAQ) 1.562 INCHES MAXIMUMARC QUENCHING METHOD(APNQ) MAGNETIC BLOWOUTACTUATOR POSITION DESIGNATION(CPRX) AT POLE ONEACTUATOR FUNCTION(CPRW) TRIP-RESETMAXIMUM INTERRUPTING CAPACITY CURRENT TYPE AND RATING PER POLE IN AMPS(CPRG) 500.0 AC ALL LOCATIONS AND 300.0 AC ALL LOCATIONSNONTURN DEVICE LOCATION(AEFN) AT 3 OCLOCK AND AT 9 OCLOCKTHREAD PITCH DIAMETERS(AAJE) +0.3503/+0.3537 INCHESUNABLE TO DECODE(PKWT) UNABLE TO DECODEOPERATING VOLTAGE TYPE AND RATING PER POLE IN VOLTS(CPRF) 120.0 AC ALL LOCATIONS AND 240.0 AC ALL LOCATIONS
