IFM Efector Inductive sensor IGT201, 12mm Range, 10-30 Vdc, Normally Closed
- Regular price
-
$57.95 - Regular price
-
- Sale price
-
$57.95
Shipping calculated at checkout.
IFM Efector Inductive sensor IGT201, 12mm Range, 10-30 Vdc, Normally Closed
Product characteristics
| Electrical design | PNP |
| Output function | normally closed |
| Sensing range[mm] | 12 |
| Housing | Threaded type |
| Dimensions[mm] | M18 x 1 / L = 50 |
Application
| System | gold-plated contacts |
| Application | Use in hygienic areas / regular cleaning processes |
Electrical data
| Operating voltage[V] | 10...30 DC |
| Current consumption[mA] | < 10 |
| Protection class | II |
| Reverse polarity protection | yes |
Outputs
| Electrical design | PNP |
| Output function | normally closed |
| Max. voltage drop switching output DC[V] | 2.5 |
| Permanent current rating of switching output DC[mA] | 100 |
| Switching frequency DC[Hz] | 300 |
| Short-circuit protection | yes |
| Type of short-circuit protection | yes (non-latching) |
| Overload protection | yes |
Monitoring range
| Sensing range[mm] | 12 |
| Real sensing range Sr[mm] | 12 ± 10 % |
| Operating distance[mm] | 0...9.72 |
Accuracy / deviations
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Hysteresis[% of Sr] | 1...20 |
| Switch-point drift[% of Sr] | -10...10 |
Operating conditions
| Ambient temperature[°C] | 0...100 |
| Protection | IP 68; IP 69K |
